Rent from venkru services for flexibility. Small in size, big on features. With new best in class latency at under 50ms, the CineView SE can transmit a video source via SDI & HDMI up to 1080p 60fps inputs/outputs. It transmits the signal on 2.4GHz+5GHz Dual-Band frequencies simultaneously for increased signal stability and sends video at an impressive maximum range of 1200ft line-of-sight.Â
Market proved wireless stability
The CineView SE utilizes dual-band transmission technology, which allows it to stream video via 2.4GHz and 5GHz Wi-Fi at the same time. The receiver can then intelligently identify interference and combine the two streams to form the complete audio and video stream.
Super low & Super far
The CineView SE is the most powerful model ever created for a faster, more responsive feel. Add to that a strong and powerful enough signal that can transmit up to 1200ft distance.
CONNECT Everything you need.
The TX and RX feature both HDMI and SDI connections that support 1080p video inputs at up to 60fps.
DESIGN
Compact and lightweight. Easy to rig.
Rugged design with a 1.3-inch OLED display that fits in the palm of your hand. The solid aerospace-grade aluminum construction keeps the weight of the units down to a minimum.
PRO POWER
Lower power draw for longer shootings.
Choose between an NP-F style battery, a DC input port (7.4V~16.8V) as well as a USB-C power source (5V).
SILENT COOLING
No noise at all
Seriously, you won’t hear any noise. And it’s very COOL.
VIEW
Monitoring as you like
Enjoy monitoring on up to 4 different devices.
SMART APP
Unlock ultra fun possibilities
Connect and instantly share previews on Accsoon GO.
LUT Loading & Recording
Monitor and preview the colors in a much better and creative way.
Onion Skin Overlay
Load a preexisting picture then compare or match the still with the live image.
Multitask with Split View on iPad
Great for working more efficiently.
Specification
| Projects | Transmitter |
|---|---|
| Video Input | SDI/HDMI |
| SDI Input Format | 1080p 23.98/24/25/29.97/30/50/59.94/60fps Level A/B |
| HDMI Input Format | 1080p 23.98/24/25/29.97/30/50/59.94/60fps |
| DC Port | 5.5mmx2.1mm center positive |
| DC Voltage | 7.4~16.8V |
| Audio | 44.1KHz/48KHz 16bit/24bit PCM |
| Latency | <0.05s (Camera latency not included) |
| OLED Display | 1.3inch |
| Transmission Power | 17~20dBm |
| Transmission Range | 1200ft (No obstacles, no interference) |
| Power Consumption | 4.5Watt (Typical) |
| Operating Environment Temperature | -10~40℃ |
| Dimensions | 105mmx66mmx32mm (Antennas not included) |
| Weight | 210g (Antennas not included) |
| Projects | Receiver |
| Video Output | SDI/HDMI |
| SDI Output Format | 1080p 24/25/30/50/60fps Level A |
| HDMI Output Format | 1080p 24/25/30/50/60fps |
| DC Port | 5.5mmx2.1mm center positive |
| DC Voltage | 7.4~16.8V |
| OLED Display | 1.3inch |
| Power Consumption | 3.5Watt (Typical) |
| Operating Environment Temperature | -10~40℃ |
| Dimensions | 105mmx66mmx32mm (Antennas not included) |
| Weight | 210g (Antennas not included) |
